Intuitive Operation, Dependability,
Performance and Value since 1972

GFC Floor Counting Scales-GFC 300

Capacity
300kg
Readability
0.02kg
Pan Size
500x400mm
View alternative models
Designed for heavy-duty industrial tasks, GFC can capably handle capacities up to 660lb/300kg. A numeric keypad facilitates unit weight and sample entry, while the easy-to-read backlit display shows total weight, unit weight and number of pieces.
Warranty 5 years

Applications

  • WeighingWeighing
  • Parts countingParts counting
  • Check countingCheck counting

Features

  • Backlit DisplayBacklit Display
  • TareTare
  • Battery PowerBattery Power
  • RS-232RS-232
  • USBUSB
  • External CalibrationExternal Calibration
  • DateDate
  • TimeTime
  • Multiple Weighing unitsMultiple Weighing units
Toggle icon descriptions
With features that facilitate checkcounting to a predefined weight or count, the GFC floor scale offers a full keypad for unit weight and sample entry. The large backlit display shows unit weight, total weight and number of pieces. A durable stainless steel platform and pillar-mounted ABS plastic indicator make the GFC suitable for most counting and weighing applications. The RS-232 interface simplies connections to printers and computers.

Features and Benefits

  • Backlit LCD shows weight, unit weight and count in one convenient location
  • Programmable backlight can be set to "always on," "always off" or "light only when weighing"
  • Adjustable levelling feet help optimise setup
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Large, grade 304 stainless steel pan allows easy cleaning
  • RS-232 interface provides speedy connection to computers and printers
  • Rugged construction stands up to industrial use
  • Rechargeable battery included for operation almost anywhere
  • Programmable auto power-off to save energy
  • Audible overload alarm warns when capacity is exceeded
  • External calibration allows for verification and adjustment with weights
  • 1:1,600,000 Internal counting resolution for precise results
  • Parts counting with freely selectable sample sizes
  • Parts counting optimisation automatically refines piece weight as parts are added
  • Preset tare function speeds the process of repetitive weighing
  • Selectable digital filtering helps minimise effects of vibration and disturbances
  • Zero-tracking feature ensures display returns to zero reading
  • User can program alarm to sound when preset total is reached
  • Product look up (PLU) memory locations store 99 items for recall
  • A 5-year warranty means quality assured for years of use.

Technical specification

Model

GFC 300

UPC: 819309012887

Metrology

  • Capacity
    • 300kg
  • Readability
    • 0.02kg
  • Repeatability
    • 20g
  • Linearity
    • 40g
  • Internal Counting Resolution
    • 1:600,000

General Specifications

  • Pan size
    • 500x400mm
  • Weighing Units
    • kg
  • Stabilisation Time
    • 2
  • Interface
    • RS-232/Optional USB
  • Calibration
    • External calibration
  • Display
    • Backlit LCD with 20mm high digits
  • PLU memories
    • 99

Power

  • Power Supply
    • Power cord / Internal rechargeable battery
  • Battery type
    • Lead Acid
  • Number of batteries
    • 1
  • Maximum Battery Life (in hours)
    • 70

Operating Conditions

  • Operating Temperature
    • -10° to 40°C / 14° to 104°F

Product Information

  • Construction
    • ABS plastic indicator with die-cast aluminum base
  • Net Weight
    • 12.5kg

Dimensions

  • Overall dims
    • 400x620x860mm
