Intuitive Operation, Dependability,
Performance and Value since 1972

AE 504 Indicator-AE 504

Capacity
Selectable
View alternative models
The AE 504 advanced label printing indicator pairs a full range of counting applications with the ability to print fully customisable labels and barcodes into a single compact solution.
Warranty 3 years

Applications

  • WeighingWeighing
  • Parts countingParts counting
  • CheckweighingCheckweighing
  • Check countingCheck counting
  • AccumulationAccumulation
  • AveragingAveraging

Features

  • Backlit DisplayBacklit Display
  • TareTare
  • Battery PowerBattery Power
  • RS-232RS-232
  • External CalibrationExternal Calibration
  • DateDate
  • TimeTime
  • Built-in PrinterBuilt-in Printer
  • Multiple Weighing unitsMultiple Weighing units
Toggle icon descriptions
A sturdy, lightweight design with a sealed keypad, an internal rechargeable battery and the convenience of a built-in printer make the AE 504 advanced label printing indicator a great choice for demanding industrial settings and shipping and receiving areas. In addition to numerous weighing and counting applications, add barcodes, QR codes, pictures and custom logos to the 50mm-wide printed labels with the indicator’s integrated printer. The large, easy-to-read backlit LCD screen features 22mm-tall digits, while a color-coded numeric keypad allows quick and easy selection from 1,000+ PLUs or to manually enter tare weights, unit weights and sample sizes. NOTE: Not for use in retail applications

Features and Benefits

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Programmable backlight can be set to "always on," "always off" or "light only when weighing"
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • RS-232 interface provides speedy connection to computers and printers
  • Rugged construction stands up to industrial use
  • Built-in printer can print weight, QR codes, bar codes and customized labels in numerous languages
  • Rechargeable battery included for operation almost anywhere
  • Programmable auto power-off to save energy
  • Zero-tracking feature ensures display returns to zero reading
  • Parts counting optimisation automatically refines piece weight as parts are added
  • Checkweighing with audible alarm
  • External calibration allows for verification and adjustment with weights
  • Quick and easy configuration using the keypad
  • User-selectable scale division
  • 1:600,000 internal counting resolution
  • A 3-year warranty means quality assured for years of use.

Technical specification

Model

AE 504

UPC: 840886105587

Metrology

  • Capacity
    • Selectable

General Specifications

  • Weighing Units
    • g, kg, lb, oz
  • Stabilisation Time
    • 2
  • Interface
    • RS-232
  • Calibration
    • External calibration
  • Display
    • Backlit LCD with 22mm high digits
  • PLU memories
    • 1006

Power

  • Power Supply
    • 12VDC 3A adapter / Internal rechargeable battery
  • Battery type
    • Lead Acid
  • Number of batteries
    • 1
  • Maximum Battery Life (in hours)
    • 200

Operating Conditions

  • Operating Temperature
    • 0° to 40°C / 32° to 104°F

Product Information

  • Construction
    • ABS plastic
  • Net Weight
    • 3.5kg

Dimensions

  • Overall dims
    • 297x121x168mm
