AE 403 Indicators
A rugged stainless steel design and IP68 rating make AE 403 the right choice for a variety of industrial applications. The back-lit display shows results in 40mm-high digits and changes color when the weight is over, under or within limits
Features
AE 403 Weight Indicator
Ideal for a variety of industrial weighing applications
All AE 403 Indicators feature a durable rugged stainless steel design that also protects against water and dust making it a perfect choice for many industrial applications. This multi-function indicator can be used in combination with a variety of Adam Equipment weighing platforms. Included with the indicator is also a bracket allowing the AE 4023 to be easily mounted making more better visibility and flexibility. The AE 403 is the successor of the previous AE 402 model.
Functions
- Weighing
- Percentage weighing
- Checkweighing
- Dynamic / animal weighing
- Parts counting
A durable IP-68 rated indicator that can withstand hard, demanding industrial environments.
Key Features
- IP68-certified for protection against water and dust
- Connects to all Adam Equipment Platforms
- Backlight changes colour (amber, red, green) for easier checkweighing
- Capacity tracker built into display for easily monitoring of possible overloads
Colour-Changing Display
The indicator's backlit display changes colour when the weight is over, under or within limits for fast, efficient checkweighing.
Wall-mount Bracket
Bracket allows for mounting the indicator on a wall or other vertical surface to easily view results.
Easy-to-Use Keypad
Colour-coded keys facilitate quick recognition of the most frequently used buttons.
Robust Stainless Steel Housing
The AE 403 indicator features a durable grade 304 stainless steel housing that protects internal components in harsh environments.
Capacity Tracker
A capacity tracker at the bottom of the display monitors the weight capacity of the attached platform from 0 to 100%.
External Calibration
A capacity tracker at the bottom of the display monitors the weight capacity of the attached platform from 0 to 100%.
Rechargeable Battery
Internal rechargeable battery allows for flexibility and easy, on-the-go use.
RS-232 Interface
Built-in RS-232 interface allows access and quick communication between computers and printers.
| AE 403 Weight Indicator | |
|---|---|
Capacity | Selectable |
| Readability | Selectable |
| Weighing Units | g, kg, lb, lb:oz, oz, N |
| Stabilization Time (Seconds) | 2 |
| Display | Backlit LCD with 40mm -high digits |
| Operating Temperature | 0° to 40°C |
| Overall Dimension | 240x145x95mm (wxdxh) |
| Power Supply | 12VDC 800mA adapter / Internal rechargeable battery |
A rugged stainless steel design and IP68 rating make AE 403 the right choice for a variety of industrial applications. The backlit display shows results in 40mm-high digits and changes color when the weight is over, under or within limits. Easily monitor overloads with the capacity tracker. The included bracket allows the AE 403 to be mounted on the wall or other vertical surface for optimum visibility and flexibility. The multi-function AE 403 indicator can be combined with weighing platforms to handle demanding industrial tasks. It performs well on the loading dock, at food processing plants, in agricultural settings, or in shipping and receiving areas. The AE 403 is the successor to the AE 402.
Features and Benefits
- Backlit display changes colour for quick notification of checkweighing limits
- Capacity tracker built into display for easily monitoring possible overloads
- Colour-coded keys facilitate quick recognition of the most frequently used buttons
- Robust metal housing protects internal components in harsh environments
- Rugged stainless steel construction for ultimate durability
- RS-232 interface provides speedy connection to computers and printers
- Wall-mount bracket for placing indicator on vertical surface
- External calibration allows for verification and adjustment with weights
- Checkweighing with audible alarm
- Hold function freezes the displayed weight, allowing time to elapse without losing the result
- Parts counting with preset sample sizes
- Selectable digital filtering for animal/dynamic weighing enables consistent results for moving subjects
- User-selectable scale division
- Zero-tracking feature ensures display returns to zero reading
- IP68-rated for protection against water and dust
- Rechargeable battery included for operation almost anywhere
- Programmable auto power-off to save energy
- 1:1,000,000 Internal counting resolution for precise results
- A 3-year warranty means quality assured for years of use.
